A2FM Series Fixed Displacement Axial Piston Hydraulic Motor

Introductions of A2FM

A2FM Series fixed displacement motors convert hydraulic energy into mechanical rotary output through a robust bent-axis axial piston mechanism. The fixed-displacement configuration provides consistent displacement per revolution, making the motor a practical choice for drives that require predictable speed and torque characteristics under varying working loads.

Key Features of A2FM

• Fixed displacement bent-axis axial piston construction for stable and efficient hydraulic power transmission.

• Compact design with high power-to-weight ratio, suitable for installations where space is limited.

• High mechanical and volumetric efficiency for dependable torque output and reduced internal energy loss.

• Strong starting performance and smooth operation across a wide working-speed range.

• Durable rotating group and bearing structure designed for demanding mobile and stationary hydraulic applications.

• Available with multiple displacement sizes, mounting flanges, shaft styles, rotation directions and port arrangements.

• Suitable for replacement, maintenance and new hydraulic drive projects when the correct technical configuration is selected.

Typical Applications of A2FM

A2FM series motors are commonly used in construction machinery, agricultural equipment, material handling systems, mining equipment, industrial machinery and other hydrostatic drive systems. Typical drive positions can include winches, conveyors, rotary mechanisms, travel or auxiliary drives, mixer systems and other equipment requiring compact, high-torque hydraulic rotation.

Configuration & Selection of A2FM

For correct replacement or project selection, the complete motor code and working conditions should be confirmed. Important information includes displacement, series, shaft type, mounting flange, port position, rotation direction, operating pressure, required speed and application. Different A2FM versions can vary significantly in external dimensions and connection details, so model-code matching is recommended before ordering.
